Introduction of Progressive die stamping Parts

This is the power connector installed inside the electronic device, it weighs 1g and is flexible. Solder wires on both contacts. The sides are designed with elastic bayonet for easy fixing inside the device. The product requires 10 stamping processes, our technical team adopts a highly efficient progressive die stamping process to meet the usage quantity of 20.000.000 pieces per year.

Copper and copper alloys are metal materials with good electrical and thermal conductivity, excellent plasticity, suitable for hot pressing or stamping, and are widely used in wires, cables, brushes, sparks, etc., requiring good electrical conductivity and corrosion resistance. strong strict environment.
In the progressive die stamping process, it is very friendly to copper materials, copper has very good ductility, and has low strength, it will not damage the die, and high-quality products can be obtained in few stamping steps.

Electronic products usually have the characteristics of huge consumption, copper-based materials, and very precise dimensional requirements, light weight, uniform wall thickness, clean and smooth surface, good conductivity, and strong corrosion resistance.
The use of progressive die stamping can completely solve these problems, which are widely used in electronics, power supply and other industries. Through the multi-functional progressive die stamping die, it can meet the requirements of completing more than 10 times of precision stamping in one stamping formation, with high efficiency and low cost. , is the preferred stamping manufacturing process in the electronic components industry.
Formtechsolution has a professional progressive die stamping factory, a professional stamping technical team, and rich manufacturing experience, and has passed ISO 9001-2015 certification and TS 16949, etc. Provide one-stop progressive die stamping parts supply business for global electronic component buyers, more than 3000+ companies choose Formtechsolution.
